Mô tả
Processor Type
Intel®
Processor Family
Intel® Xeon® Scalable 8300 series Intel® Xeon® Scalable 6300 series
Processor Core Available
8 to 40 core, depending on processor
Processor Cache Installed
12 – 60 MB L3, depending on processor
Maximum Memory
6.0 TB per socket, when populated with 256 GB DDR4 and 512 GB Persistent Memory
Memory Slots
16 DIMM slots per socket
Memory Type
HPE DDR4 SmartMemory
NVDIMM Type
Optional: Intel® Optane™ Persistent Memory for HPE
NVDIMM Capacity
Optional: 128 to 512 GB
Memory Protection Features
HPE Fast Fault Tolerant Memory Advanced ECC Memory Online Spare Memory Mirrored Memory
Drive Supported
Up to 4 LFF SAS/SATA HDDs or SSDs Up to 10 SFF SAS/SATA HDDs or SATA/SAS/NVMe U.2 or U.3 SDDs, depending on model
Network Controller
Wide range of speeds, cabling, chipsets and form factors. Please see QuickSpecs for network card choices
Remote Management Software
Included – HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional – HPE iLO Advanced, and HPE OneView Advanced
Expansion Slots
Maximum 3 PCIe Gen4, for detail descriptions please see QuickSpecs
Storage Controller
Included – Embedded SATA controller (AHCI or SR100i modes) Optional – Variety of protocols -including NVMe-, port count, array utilities, and form factors. Please see QuickSpecs for storage controllers selection
Warranty Standard Statement
3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, visit http://www.hpe.com/support
Processor Name
3rd Generation Intel® Xeon® Scalable Processor Family
Processor Number
1 or 2
Processor Speed
3.6 GHz, maximum depending on processor
Standard Memory
4 TB (16x 256 GB) RDIMM per socket 6 TB (8x 256 GB RDIMM and 8x 512 GB Persistent Memory) per socket, depending on processor model
Security
UEFI Secure Boot and Secure Start support Intel® Software Guard Extensions (SGX) support Immutable Silicon Root of Trust Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits
Form Factor
1U Rack
Weight (imperial)
SFF: 28.74 lb to 35.86 lb LFF: 30.36 lb to 37.00 lb
Weight (metric)
SFF: 13.04 kg to 16.27 kg LFF: 13.77 kg to 16.78 kg
Product Dimensions (imperial)
SFF: 1.69 x 17.11 x 30.30 in LFF: 1.69 x 17.11 x 31.50 in
Product Dimensions (metric)
SFF: 4.29 x 43.46 x 76.96 cm LFF: 4.29 x 43.46 x 80.01 cm
Persistent Memory Type
Optional: Intel® Optane™ Persistent Memory for HPE
Persistent Memory Media Capacity
Optional: 128 to 256 GB
